Level Indicator

"BOMBAY INSTRUMENTS MFG. CO." Make Float & Board Type Level Indicator fabricated from the following parts : Our Model No. : 11 Board : Aluminium powder coated having 150 mm width & acid proof paint marking at every 10 cm with PP roller for frictionless sliding on board . Mounting brackets and suitable hardware will provide as per tank height. Min. Graduation : 100 MM Cable Float : SS.304 Float Assembly : SS.316 Sheave Assembly : Pulley Housing : Al. Die Cost acid proof Top Board Connector : Steel Board Bracket : Steel Indicator Assembly : Steel Guide wire Indicator/rope : SS.304 Bottom Bracket : Steel Tank Length : 3 mtr Mounting : 1ï NB, ASA 150 Flange. Qty : 01 Nos. All wetted Parts : SS.304 Nozzle length : 800 MM Adjustable Make : BIMCO - Bombay Instrument Scope of Supply : - Complete assembly will be provided. It include Scale with radium numbering , Indicator with radium Brackets to fix Scale & wall of tank, Indicator rope, Float, Float rope, Locable pin to lock float & indicator by rope, Pulley assembly, Pulley housing , 800mm Adjustable pipe for fixing on Top of tank with flange in-build with pulley housing.

Model No. : 09 - RI Type : Magnetic Mounting : Top Top Chamber : SS.304/316/PP etc Pipe flared and flanged at Top end and having flanged cover at bottom end Guide Pipe : A perforated G.I/SS.304/316/PP etc. Pipe Flange : 4ï /6ïNB, ASA 150 C.S./any MOC Flange Test Pressure : 5 Kg/CM-2 / high Pressure as per requiest Float : SS.316./any moc float with SS.304 stem and cartridge made out of SS./anymoc having Powerful permanent magnet inside it. All wetted Parts : SS.304/316/PP /GI./Any MOC By-pass Pipe : SS.304/316/PP /GI./Any MOC OP.Temp. : AMB. / Pl. confirm OP. Pressure : AMB. /Pl. confirm Scale : Black Anodised Aluminium scale marked in CMS Least count 5 mm Indication : BI-COLOUR Magnetic PP. Roller will be in Powder coated Al. housing with transparent acrylic Front. Protection : Al. powder Coated housing with Roller Liquid : Water / Pl. mention if other liquid. Tank Depth : Pl. mention Nozzle length : Pl. mention Make : BIMCO- Bombay Instrument

Heavy Duty Tubular Level Model No. : BIMCO05 -1 Type : Tubular with "Cï Frame Guards. Make : BIMCO - Bombay Instrument

NON CONTACT TYPE ULTRASONIC LEVEL INDICATOR CUM TRANSMITTER MODEL NO. : BI-A-5 Range : 5 Mtrs./10mtr/15mtr/30mtr .(Range adjustable over entire range) Indication : Inbuilt Out Put : 4-20mA Display : Liquid level in tank OLED (Inbuilt with Sensor) Protection : IP-65 Make : BIMCO - Bombay Instrument

Model No : 11-PROWL Application : Level measurement Length : Please confirm Uses : Water level alarm Tape : Graduation in mm, cm and m Probe : SS.304, Waterproof IP 68 Tape MOC : High Tensile steel two anticorrosive beside with two core conductor waterproof IP68 Supply : Battery Make : BIMCO - Bombay Instrument
